Detailed operation steps of slope greening equipment

Time：2025-07-08　Click：61

1) After the diesel engine is started. It should not be operated at full capacity. When the cooling water temperature reaches 60 degrees, the diesel engine should be heated at low speed to increase speed and full load.

2) Appropriately increase the throttle, pull down and open the mixing rod, while observing the mixing situation inside the box, and gradually adjust the mixing speed to the appropriate level. If reverse stirring is used in work, it should be stopped during the transition and pulled down again.

3) When the pump switch is turned off, the sprayed material enters the box through the circulation pipe for jet circulation.

5) According to the ratio of spraying materials, add the spraying substrate to the stirred material in sequence. It should be noted that it should be evenly dispersed and not poured in large quantities to avoid the formation of colloidal packaging, which may affect the spraying effect.

6) All materials are evenly mixed and stirred at low speed or stop, the power clutch is disengaged, the injection valve is opened, and the circulation valve is closed.

7) Keep the spray gun control lever in the spraying direction, place the power clutch in the open position, gradually increase the throttle, and enter the spraying structure.

8) Before use, please check the connection of the positive and negative terminals of the battery. Check whether the screws of each part of the machine are loose, whether there are large foreign objects, and whether the diesel engine has enough diesel.

9) After inspection, fill the diesel tank with water and add diesel from the mailbox (add 10 diesel in winter). Add an appropriate amount of water to the water tank as needed.

10) Start the engine on the diesel engine for top mixing. After starting, lower the clutch behind the operating platform, then hang the gear in the positive direction and increase or decrease the throttle control as needed until fully mixed.

11) When stopping use, simply reduce the throttle and turn off the engine.

The above is the introduction of the operation steps of slope greening equipment brought to you by the editor, hoping to be helpful to everyone!
